Photo | Mfr. Part # | Stock | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
IKB20N60TATMA1IGBT 600V 40A 166W TO263-3 |
2349 | 3.40 |
ДобавитьРасследования |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | TrenchStop® | Active | Trench Field Stop | 600 V | 40 A | 60 A | 2.05V @ 15V, 20A | 166 W | 770µJ | Standard | 120 nC | 18ns/199ns | 400V, 20A, 12Ohm, 15V | 41 ns | -40°C ~ 175°C (TJ) | Surface Mount | |
IGW30N60TPXKSA1IGBT TRENCH/FS 600V 53A TO247-3 |
3836 | 2.86 |
ДобавитьРасследования |
Datasheet |
Tube | TrenchStop™ | Not For New Designs | Trench Field Stop | 600 V | 53 A | 90 A | 1.8V @ 15V, 30A | 200 W | 710µJ (on), 420µJ (off) | Standard | 130 nC | 15ns/179ns | 400V, 30A, 10.5Ohm, 15V | - | -40°C ~ 175°C (TJ) | Through Hole | |
HGTG10N120BNDIGBT NPT 1200V 35A TO247-3 |
2135 | 4.14 |
ДобавитьРасследования |
Datasheet |
Tube | - | Last Time Buy | NPT | 1200 V | 35 A | 80 A | 2.7V @ 15V, 10A | 298 W | 850µJ (on), 800µJ (off) | Standard | 100 nC | 23ns/165ns | 960V, 10A, 10Ohm, 15V | 70 ns | -55°C ~ 150°C (TJ) | Through Hole | |
FGH60N60SMDIGBT FIELD STOP 600V 120A TO247 |
3583 | 5.79 |
ДобавитьРасследования |
Datasheet |
Tube | - | Active | Field Stop | 600 V | 120 A | 180 A | 2.5V @ 15V, 60A | 600 W | 1.26mJ (on), 450µJ (off) | Standard | 189 nC | 18ns/104ns | 400V, 60A, 3Ohm, 15V | 39 ns | -55°C ~ 175°C (TJ) | Through Hole | |
FGH80N60FD2TUIGBT 600V 80A 290W TO247 |
3164 | 5.28 |
ДобавитьРасследования |
Datasheet |
Tube | - | Active | Field Stop | 600 V | 80 A | 160 A | 2.4V @ 15V, 40A | 290 W | 1mJ (on), 520µJ (off) | Standard | 120 nC | 21ns/126ns | 400V, 40A, 10Ohm, 15V | 61 ns | -55°C ~ 150°C (TJ) | Through Hole | |
IGW25N120H3FKSA1IGBT 1200V 50A 326W TO247-3 |
3417 | 6.08 |
ДобавитьРасследования |
Datasheet |
Tube | TrenchStop® | Active | Trench Field Stop | 1200 V | 50 A | 100 A | 2.4V @ 15V, 25A | 326 W | 2.65mJ | Standard | 115 nC | 27ns/277ns | 600V, 25A, 23Ohm, 15V | - | -40°C ~ 175°C (TJ) | Through Hole | |
IGW40N120H3FKSA1IGBT 1200V 80A 483W TO247-3 |
3932 | 7.19 |
ДобавитьРасследования |
Datasheet |
Tube | TrenchStop® | Active | Trench Field Stop | 1200 V | 80 A | 160 A | 2.4V @ 15V, 40A | 483 W | 3.16mJ | Standard | 185 nC | 30ns/290ns | 600V, 40A, 12Ohm, 15V | - | -40°C ~ 175°C (TJ) | Through Hole | |
IKW75N60TFKSA1IGBT TRENCH/FS 600V 80A TO247-3 |
3595 | 9.25 |
ДобавитьРасследования |
Datasheet |
Tube | TrenchStop® | Active | Trench Field Stop | 600 V | 80 A | 225 A | 2V @ 15V, 75A | 428 W | 4.5mJ | Standard | 470 nC | 33ns/330ns | 400V, 75A, 5Ohm, 15V | 121 ns | -40°C ~ 175°C (TJ) | Through Hole | |
APT75GN60LDQ3GIGBT 600V 155A 536W TO264 |
3720 | 10.42 |
ДобавитьРасследования |
Datasheet |
Tube | - | Active | Trench Field Stop | 600 V | 155 A | 225 A | 1.85V @ 15V, 75A | 536 W | 2500µJ (on), 2140µJ (off) | Standard | 485 nC | 47ns/385ns | 400V, 75A, 1Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole | |
APT50GS60BRDQ2GIGBT 600V 93A 415W TO247 |
3818 | 13.36 |
ДобавитьРасследования |
Datasheet |
Tube | Thunderbolt IGBT® | Active | NPT | 600 V | 93 A | 195 A | 3.15V @ 15V, 50A | 415 W | 755µJ (off) | Standard | 235 nC | 16ns/225ns | 400V, 40A, 4.7Ohm, 15V | 25 ns | -55°C ~ 150°C (TJ) | Through Hole | |
IKQ120N60TXKSA1IGBT 600V 160A TO247-3-46 |
3928 | 13.45 |
ДобавитьРасследования |
Datasheet |
Tube | TrenchStop™ | Active | Trench Field Stop | 600 V | 160 A | 480 A | 2V @ 15V, 120A | 833 W | 6.2mJ (on), 5.9mJ (off) | Standard | 703 nC | 50ns/565ns | 400V, 120A, 3Ohm, 15V | 241 ns | -40°C ~ 175°C (TJ) | Through Hole | |
IXYK140N90C3IGBT 900V 310A 1630W TO264 |
642 | 20.74 |
ДобавитьРасследования |
Datasheet |
Tube | GenX3™, XPT™ | Active | - | 900 V | 310 A | 840 A | 2.7V @ 15V, 140A | 1630 W | 4.3mJ (on), 4mJ (off) | Standard | 330 nC | 40ns/145ns | 450V, 100A, 1Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole | |
IXGH32N170IGBT 1700V 75A 350W TO247AD |
2186 | 22.76 |
ДобавитьРасследования |
Datasheet |
Tube | - | Active | NPT | 1700 V | 75 A | 200 A | 3.3V @ 15V, 32A | 350 W | 11mJ (off) | Standard | 155 nC | 45ns/270ns | 1020V, 32A, 2.7Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole | |
IXBH42N170IGBT 1700V 80A 360W TO247 |
547 | 27.91 |
ДобавитьРасследования |
Datasheet |
Bulk | BIMOSFET™ | Active | - | 1700 V | 80 A | 300 A | 2.8V @ 15V, 42A | 360 W | - | Standard | 188 nC | - | - | 1.32 µs | -55°C ~ 150°C (TJ) | Through Hole | |
IXXX300N60B3IGBT 600V 550A 2300W TO247 |
873 | 33.41 |
ДобавитьРасследования |
Datasheet |
Tube | GenX3™, XPT™ | Active | PT | 600 V | 550 A | 1140 A | 1.6V @ 15V, 100A | 2300 W | 3.45mJ (on), 2.86mJ (off) | Standard | 460 nC | 50ns/190ns | 400V, 100A, 1Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole | |
IXYX30N170CV11700V/108A HIGH VOLTAGE XPT IGB |
3146 | 24.87 |
ДобавитьРасследования |
Datasheet |
Tube | XPT™ | Active | - | 1700 V | 108 A | 255 A | 3.7V @ 15V, 30A | 937 W | 5.9mJ (on), 3.3mJ (off) | Standard | 140 nC | 28ns/150ns | 850V, 30A, 2.7Ohm, 15V | 160 ns | -55°C ~ 175°C (TJ) | Through Hole | |
IXYT25N250CHVIGBT 2500V 235A TO-268HV |
3172 | 35.04 |
ДобавитьРасследования |
Datasheet |
Tube | XPT™ | Active | - | 2500 V | 95 A | 235 A | 4V @ 15V, 25A | 937 W | 8.3mJ (on), 7.3mJ (off) | Standard | 147 nC | 15ns/230ns | 1250V, 25A, 5Ohm, 15V | 34 ns | -55°C ~ 175°C (TJ) | Surface Mount | |
IXBX25N250IGBT 2500V 55A 300W PLUS247 |
677 | 42.17 |
ДобавитьРасследования |
Datasheet |
Tube | BIMOSFET™ | Active | - | 2500 V | 55 A | 180 A | 3.3V @ 15V, 25A | 300 W | - | Standard | 103 nC | - | - | 1.6 µs | -55°C ~ 150°C (TJ) | Through Hole | |
IXBK75N170IGBT 1700V 200A 1040W TO264 |
487 | 62.39 |
ДобавитьРасследования |
Datasheet |
Tube | BIMOSFET™ | Active | - | 1700 V | 200 A | 580 A | 3.1V @ 15V, 75A | 1040 W | - | Standard | 350 nC | - | - | 1.5 µs | -55°C ~ 150°C (TJ) | Through Hole | |
IXYX140N120A4IGBT 140A 1200V PLUS247 |
405 | 40.44 |
ДобавитьРасследования |
Datasheet |
Tube | XPT™, GenX4™ | Active | PT | 1200 V | 480 A | 1200 A | 1.7V @ 15V, 140A | 1500 W | 4.9mJ (on), 12mJ (off) | Standard | 420 nC | 52ns/590ns | 600V, 70A, 1.5Ohm, 15V | 47 ns | -55°C ~ 175°C (TJ) | Through Hole |
