Photo | Mfr. Part # | Stock | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
IRG4RC10KDTRPBFSHORT CIRCUIT RATED ULTRAFAST IG |
3235 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 9 A | 18 A | 2.62V @ 15V, 5A | 38 W | 250µJ (on), 140µJ (off) | Standard | 29 nC | 49ns/97ns | 480V, 5A, 100Ohm, 15V | 28 ns | -55°C ~ 150°C (TJ) | Surface Mount | |
IRG4PSH71UDPBFULTRAFAST COPACK IGBT W/ULTRAFAS |
3645 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 1200 V | 99 A | 200 A | 2.7V @ 15V, 70A | 350 W | 8.8mJ (on), 9.4mJ (off) | Standard | 570 nC | 46ns/250ns | 960V, 70A, 5Ohm, 15V | 110 ns | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4PSC71UDPBFULTRAFAST COPACK IGBT W/ULTRAFAS |
2523 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 85 A | 200 A | 2V @ 15V, 60A | 350 W | 3.26mJ (on), 2.27mJ (off) | Standard | 340 nC | 90ns/245ns | 480V, 60A, 5Ohm, 15V | 82 ns | -55°C ~ 150°C (TJ) | Through Hole | |
RGT8BM65DTLIGBT 650V 8A 62W TO-252 |
3679 | 2.33 |
Add To CartInquiry Now |
Datasheet |
Cut Tape (CT),Digi-Reel® | - | Not For New Designs | Trench Field Stop | 650 V | 8 A | 12 A | 2.1V @ 15V, 4A | 62 W | - | Standard | 13.5 nC | 17ns/69ns | 400V, 4A, 50Ohm, 15V | 40 ns | -40°C ~ 175°C (TJ) | Surface Mount | |
IRG4PC50UPBFIGBT, 55A I(C), 600V V(BR)CES, N |
2825 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Tube | - | Active | - | 600 V | 55 A | 220 A | 2V @ 15V, 27A | 200 W | 120µJ (on), 540µJ (off) | Standard | 180 nC | 32ns/170ns | 480V, 27A, 5Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole | |
IRGB15B60KDPBFIGBT, 31A I(C), 600V V(BR)CES, N |
3087 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | NPT | 600 V | 31 A | 62 A | 2.2V @ 15V, 15A | 208 W | 220µJ (on), 340µJ (off) | Standard | 84 nC | 34ns/184ns | 400V, 15A, 22Ohm, 15V | 92 ns | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4PH30KPBFSHORT CIRCUIT RATED ULTRAFAST IG |
2960 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 1200 V | 20 A | 40 A | 4.2V @ 15V, 10A | 100 W | 640µJ (on), 920µJ (off) | Standard | 53 nC | 28ns/200ns | 960V, 10A, 23Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4PC50UD-EPBF600V ULTRAFAST 8-60 KHZ COPACK I |
3539 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 55 A | 220 A | 2V @ 15V, 27A | 200 W | 990µJ (on), 590µJ (off) | Standard | 180 nC | 46ns/140ns | 480V, 27A, 5Ohm, 15V | 50 ns | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4PH50UPBFULTRA FAST SPEED IGBT |
2815 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 1200 V | 45 A | 180 A | 3.7V @ 15V, 24A | 200 W | 530µJ (on), 1.41mJ (off) | Standard | 160 nC | 35ns/200ns | 960V, 24A, 5Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4RC10UDTRRPULTRAFAST COPACK IGBT W/ULTRAFAS |
3459 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 8.5 A | 34 A | 2.6V @ 15V, 5A | 38 W | 140µJ (on), 120µJ (off) | Standard | 15 nC | 40ns/87ns | 480V, 5A, 100Ohm, 15V | 28 ns | -55°C ~ 150°C (TJ) | Surface Mount | |
SGB20N35CLIGBT D2PAK SP 350V TR |
2848 | 1.00 |
Add To CartInquiry Now |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ||
IRGS4056DPBFIGBT W/ULTRAFAST SOFT RECOVERY D |
3863 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | Trench | 600 V | 24 A | 48 A | 1.85V @ 15V, 12A | 140 W | 75µJ (on), 225µJ (off) | Standard | 25 nC | 31ns/83ns | 400V, 12A, 22Ohm, 15V | 68 ns | -55°C ~ 175°C (TJ) | Surface Mount | |
IRG4PC30SPBFIRG4PC30 - TRANS IGBT CHIP N-CH |
2771 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 34 A | 68 A | 1.6V @ 15V, 18A | 100 W | 260µJ (on), 3.45mJ (off) | Standard | 50 nC | 22ns/540ns | 480V, 18A, 23Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4PC40SPBFIGBT 600V 60A 160W TO247AC |
2266 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 60 A | 120 A | 1.5V @ 15V, 31A | 160 W | 450µJ (on), 6.5mJ (off) | Standard | 100 nC | 22ns/650ns | 480V, 31A, 10Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole | |
FGD3440G2IGBT 26.9A, 450V, N CHANNEL, DPA |
3016 | 1.00 |
Add To CartInquiry Now |
Bulk | EcoSPARK® | Active | - | 400 V | 26.9 A | - | 1.2V @ 4V, 6A | 166 W | - | Logic | 24 nC | -/5.3µs | 300V, 6.5A, 1kOhm, 5V | - | -40°C ~ 175°C (TJ) | Surface Mount | ||
AUIRGB4062D1IGBT, 59A I(C), 600V V(BR)CES, N |
2285 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | Trench | 600 V | 59 A | 72 A | 1.77V @ 15V, 24A | 246 W | 532µJ (on), 311µJ (off) | Standard | 77 nC | 19ns/90ns | 400V, 24A, 10Ohm, 15V | 102 ns | -55°C ~ 175°C (TJ) | Through Hole | |
AUIRGF65G40D0IGBT |
2375 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | CooliRIGBT™ | Active | - | 600 V | 62 A | 84 A | 2.2V @ 15V, 20A | 625 W | 298µJ (on), 147µJ (off) | Standard | 270 nC | 35ns/142ns | 400V, 20A, 4.7Ohm, 15V | 41 ns | -55°C ~ 175°C (TJ) | Through Hole | |
HGTP14N0FVLR4600HGTP14N0FVLR4600 |
3022 | 1.00 |
Add To CartInquiry Now |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ||
IRG4PC50SDPBFSTANDARD SPEED COPACK IGBT W/ULT |
3985 | 1.00 |
Add To CartInquiry Now |
Datasheet |
Bulk | - | Active | - | 600 V | 70 A | 140 A | 1.36V @ 15V, 41A | 200 W | 720µJ (on), 8.27mJ (off) | Standard | 280 nC | 33ns/650ns | 480V, 41A, 5Ohm, 15V | 50 ns | -55°C ~ 150°C (TJ) | Through Hole | |
IRG4PC50F-EPBFFAST SPEED IGBT |
2859 | 1.00 |
Add To CartInquiry Now |
Bulk | - | Active | - | 600 V | 70 A | 280 A | 1.6V @ 15V, 39A | 200 W | 370µJ (on), 2.1mJ (off) | Standard | 190 nC | 31ns/240ns | 480V, 39A, 5Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole |
