Photo | Mfr. Part # | Stock | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | SwitchCircuit | Multiplexer/DemultiplexerCircuit | NumberofCircuits | On-StateResistance(Max) | Channel-to-ChannelMatching(ΔRon) | Voltage-SupplySingle(V+) | Voltage-SupplyDual(V±) | SwitchTime(TonToff)(Max) | -3dbBandwidth | ChargeInjection | ChannelCapacitance(CS(off)CD(off)) | Current-Leakage(IS(off))(Max) | Crosstalk | OperatingTemperature | MountingType |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
QS3253S0FCT SERIES QUICKSWITCH DUAL 4:1 |
1449 | 1.96 |
Add To CartInquiry Now |
- | Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ||
ISL43144IVSPST, 4 FUNC, 1 CHANNEL, CMOS |
2223 | 1.97 |
Add To CartInquiry Now |
Datasheet |
16-TSSOP (0.173, 4.40mm Width) | Bag | - | Obsolete | SPST - NO | 1:1 | 4 | 25Ohm | 500mOhm | 2.7V ~ 12V | ±2.6V ~ 6V | 65ns, 50ns | - | 5pC (Max) | 10pF, 26pF | 100pA | -89dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount | |
DG441EJQUAD SPST ANALOG SWITCH |
1188 | 2.00 |
Add To CartInquiry Now |
Datasheet |
16-DIP (0.300, 7.62mm) | Bulk | - | Active | SPST | 1:1 | 4 | 85Ohm | - | ±15V | ±15V | 250ns, 120ns | - | 1pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | -40°C ~ 85°C | Through Hole | |
ISL43L120IRZSPDT, 2 FUNC, 2 CHANNEL, CMOS |
13289 | 2.03 |
Add To CartInquiry Now |
Datasheet |
8-WDFN Exposed Pad | Tube | - | Obsolete | SPST - NO | 1:1 | 2 | 250mOhm | 5mOhm | 1.65V ~ 3.6V | - | 25ns, 25ns | - | -125pC | 182pF, 182pF | 3nA | -94dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount | |
ISL84762IRZSPDT ANALOG SWITCH, 2 FUNC, 1 CH |
8036 | 2.03 |
Add To CartInquiry Now |
Datasheet |
10-VFDFN Exposed Pad | Tube | - | Obsolete | SPDT | 2:1 | 2 | 600mOhm | 50mOhm | 1.65V ~ 3.6V | - | 20ns, 12ns | - | 95pC | 115pF | 2nA | -95dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount | |
MAX4659EUA+TIC SWITCH SPDT 8UMAX |
549 | 6.17 |
Add To CartInquiry Now |
Datasheet |
8-TSSOP, 8-MSOP (0.118, 3.00mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | SPDT | 2:1 | 1 | 25Ohm | 400mOhm | 9V ~ 40V | ±4.5V ~ 20V | - | 225MHz | 1.5pC | 6pF | 1nA | -76dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount | |
ADG5401FBCPZ-RL760V OV PROTECTED HV SPSTX1 SWITC |
1327 | 7.29 |
Add To CartInquiry Now |
Datasheet |
10-WFDFN, CSP | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | SPST - NC | 1:1 | 1 | 6Ohm (Typ) | - | 8V ~ 44V, ±5V ~ 22V | 8V ~ 44V, ±5V ~ 22V | 10.2µs, 360ns | 395MHz | -230pC | 9pF, 11pF | 100pA (Typ) | - | -40°C ~ 125°C | Surface Mount | |
MUX36D08IPWRIC MUX DUAL 8:1 170 OHM 28TSSOP |
1020 | 6.58 |
Add To CartInquiry Now |
Datasheet |
28-TSSOP (0.173, 4.40mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | - | 8:1 | 2 | 170Ohm | 6Ohm | 10V ~ 36V | ±5V ~ 18V | 136ns, 78ns | - | 0.31pC | 3pF, 7.5pF | 40pA | -100dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount | |
MUX36S16IDWRIC SWITCH SINGLE 28SOIC |
440 | 6.58 |
Add To CartInquiry Now |
Datasheet |
28-SOIC (0.295, 7.50mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | - | 16:1 | 1 | 170Ohm | 6Ohm | 10V ~ 36V | ±5V ~ 18V | 136ns, 78ns | - | 0.67pC | 3pF, 12.2pF | 40pA | -99db @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount | |
MUX36D04IPWRIC MUX 4:1 LOCAP CMOS 16TSSOP |
2124 | 6.62 |
Add To CartInquiry Now |
Datasheet |
16-TSSOP (0.173, 4.40mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | - | 4:1 | 2 | 170Ohm | 2.4Ohm | 10V ~ 36V | ±5V ~ 18V | 136ns, 75ns | - | 0.3pC | 2.4pF, 4.3pF | 400pA | -96dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount | |
ISL84521IVZ-TSPST ANALOG SWITCH, 4 FUNC, 1 CH |
2220 | 2.03 |
Add To CartInquiry Now |
Datasheet |
16-TSSOP (0.173, 4.40mm Width) | Bulk | - | Active | SPST - NC | 1:1 | 4 | 100Ohm | 1Ohm | 2V ~ 12V, ±2V ~ 6V | 2V ~ 12V, ±2V ~ 6V | 80ns, 30ns | - | 1pC | 2pF, 2pF | 1nA | -90dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount | |
MAX4529EUTLOW VOLTAGE, BIDIRECTIONAL RF/VI |
245 | 2.04 |
Add To CartInquiry Now |
- | Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ||
ISL84762IRZ-TSPDT ANALOG SWITCH, 2 FUNC, 1 CH |
18000 | 2.11 |
Add To CartInquiry Now |
Datasheet |
10-VFDFN Exposed Pad | Bulk | - | Obsolete | SPDT | 2:1 | 2 | 600mOhm | 50mOhm | 1.65V ~ 3.6V | - | 20ns, 12ns | - | 95pC | 115pF | 2nA | -95dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount | |
DG528CYANALOG LATCHABLE MUX, 8-CHANNEL |
1503 | 2.12 |
Add To CartInquiry Now |
Datasheet |
18-SOIC (0.295, 7.50mm Width) | Bulk | - | Active | - | 8:1 | 1 | 450Ohm | 27Ohm | 44V | 44V | 1µs (Typ), 400ns (Typ) | - | 4pC | 5pF, 25pF | 5nA | - | 0°C ~ 70°C | Surface Mount | |
MAX4693EGETRIPLE SPDT IN UCSP PACKAGE |
16797 | 2.17 |
Add To CartInquiry Now |
Datasheet |
- | Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
DG412EJQUAD SPST ANALOG SWITCH |
1842 | 2.17 |
Add To CartInquiry Now |
Datasheet |
16-DIP (0.300, 7.62mm) | Bulk | - | Active | SPST | 1:1 | 4 | 35Ohm | - | ±15V | ±15V | 145ns, 145ns | - | 5pC | 9pF, 9pF | 250pA | -85dB @ 1MHz | -40°C ~ 85°C | Through Hole | |
ISL8484IRZ-TSPDT ANALOG SWITCH, 2 FUNC, 1 CH |
22231 | 2.25 |
Add To CartInquiry Now |
Datasheet |
10-VFDFN Exposed Pad | Bulk | - | Obsolete | SPDT | 2:1 | 2 | 500mOhm | 60mOhm | 1.65V ~ 4.5V | - | 40ns, 20ns | - | 170pC | 62pF | 100nA | -85dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount | |
DG409DJDUAL 4-CHANNEL CMOS ANALOG MUX |
1621 | 2.27 |
Add To CartInquiry Now |
Datasheet |
16-DIP (0.300, 7.62mm) | Tube | - | Obsolete | SP4T | 4:1 | 2 | 100Ohm | 15Ohm (Max) | 5V ~ 34V, ±5V ~ 20V | 5V ~ 34V, ±5V ~ 20V | 150ns, 150ns | - | 20pC | 3pF, 14pF | 500pA | - | -40°C ~ 85°C (TA) | Through Hole | |
DG508ABYCMOS ANALOG MULTIPLEXER |
8745 | 2.30 |
Add To CartInquiry Now |
Datasheet |
16-SOIC (0.295, 7.50mm Width) | Bulk | - | Active | - | 8:1 | 1 | 450Ohm | 27Ohm | 44V | 44V | 1µs (Typ), 400ns (Typ) | - | 6pC | 5pF, 25pF | 5nA | - | -25°C ~ 85°C | Surface Mount | |
MAX4619EGEHIGH-SPEED, LOW VOLTAGE, CMOS AN |
9702 | 2.31 |
Add To CartInquiry Now |
- | Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
