| Photo | Mfr. Part # | Stock | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | SwitchType | NumberofOutputs | Ratio-Input:Output | OutputConfiguration | OutputType | Interface | Voltage-Load | Voltage-Supply(Vcc/Vdd) | Current-Output(Max) | RdsOn(Typ) | InputType | Features | FaultProtection | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MP6412GQGU-ZULTRA-LOW IQLOAD-SWITCH CONTROLL |
5000 | 0.27 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | - | P-Channel | - | 2.2V ~ 12V | Not Required | - | 150mOhm | Non-Inverting | - | Over Temperature, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
MP5032GJ-ZIC PWR SWTCH P-CHAN 1:1 TSOT23-8 |
3000 | 1.47 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | USB Switch | 1 | 1:1 | - | P-Channel | - | 14V (Max) | - | 3A | 32mOhm | - | - | - | -40°C ~ 125°C (TJ) | Surface Mount |
|
MPQ5071GG-AEC1-Z5.5V, 0.5A, LOW RDS(ON) LOAD SWI |
2860 | 1.08 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | - | 0.5V ~ 5.5V | Not Required | 500mA | 50mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MP5095GJ-ZIC PWR SWTCH P-CHAN 2:2 TSOT23-8 |
2420 | 0.87 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 2 | 2:2 | High Side | P-Channel | On/Off | 5.5V | 1.85V ~ 5.5V | 2.3A | 35mOhm | - | Slew Rate Controlled | Over Temperature, Short Circuit | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MPQ5072GG-AEC1-Z5.5V, 1A LOW RDS(ON) LOAD SWITCH |
4960 | 1.22 |
Add To CartInquiry Now |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q100 | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 0.5V ~ 5.5V | 3V ~ 5.5V | 1A | 60mOhm | Non-Inverting | Load Discharge, Power Good, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | Surface Mount | |
|
MPQ5069GQV-AEC1-P7M PROTECTION SWITCH WITH CURREN |
128 | 6.36 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q100 | Active | General Purpose | 1 | 1:1 | High Side | - | On/Off | 6V ~ 28V | Not Required | 15A | 7mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled | Current Limiting (Adjustable), Over Temperature, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MPQ5071GG-AEC1-P5.5V, 0.5A, LOW RDS(ON) LOAD SWI |
500 | 1.61 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | - | 0.5V ~ 5.5V | Not Required | 500mA | 50mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MPQ5072GG-AEC1-P5.5V, 1A LOW RDS(ON) LOAD SWITCH |
500 | 1.56 |
Add To CartInquiry Now |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q100 | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 0.5V ~ 5.5V | 3V ~ 5.5V | 1A | 60mOhm | Non-Inverting | Load Discharge, Power Good, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | Surface Mount | |
|
MP5073GG-PIC PWR SWITCH P-CHAN 1:1 12QFN |
484 | 1.50 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | P-Channel | On/Off | 0.5V ~ 5.5V | 3V ~ 5.5V | 2A | 50mOhm | - | Load Discharge, Power Good, Slew Rate Controlled | Current Limiting (Adjustable), Over Temperature, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MP5013AGJ-PIC PWR SWTCH N-CHAN 1:1 TSOT23-8 |
350 | 1.59 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 3V ~ 5.5V | Not Required | 5A | 36mOhm | - | Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
MP5087GG-ZIC PWR SWITCH P-CHAN 1:1 12QFN |
4098 | 1.36 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | P-Channel | On/Off | 0.5V ~ 5.5V | 3V ~ 5.5V | 7A | 10mOhm | - | Load Discharge, Power Good, Slew Rate Controlled | Over Temperature, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
MP5016GQH-ZIC PWR LMT SWITCH N-CH 1:1 10QFN |
3397 | 1.61 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 15V | 2.7V ~ 15V | 5A | 43mOhm | - | Slew Rate Controlled | Over Current, Over Voltage | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MPQ5069GQV-AEC1-Z7M PROTECTION SWITCH WITH CURREN |
3806 | 6.66 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q100 | Active | General Purpose | 1 | 1:1 | High Side | - | On/Off | 6V ~ 28V | Not Required | 15A | 7mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled | Current Limiting (Adjustable), Over Temperature, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MP5073GG-ZIC PWR SWITCH P-CHAN 1:1 12QFN |
2170 | 0.98 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | P-Channel | On/Off | 0.5V ~ 5.5V | 3V ~ 5.5V | 2A | 50mOhm | - | Load Discharge, Power Good, Slew Rate Controlled | Current Limiting (Adjustable), Over Temperature, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
MP5036GJ-Z12V, 0.4A TO 5A, CURRENT LIMIT S |
3891 | 1.05 |
Add To CartInquiry Now |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | Low Side | P-Channel | - | 2.9V ~ 14V | Not Required | 5A | 43mOhm | - | Load Discharge, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Over Voltage, UVLO | -40°C ~ 125°C (TJ) | Surface Mount | |
|
MP5075GTF-PIC PWR SWITCH P-CHAN 1:1 SOT563 |
3889 | 0.94 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | P-Channel | On/Off | 3V ~ 5.5V | 3V ~ 5.5V | 2.4A | 38mOhm | - | Load Discharge, Power Good, Slew Rate Controlled | Over Current, Over Temperature, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
MP5000ADQ-LF-ZIC PWR SWITCH N-CHAN 1:1 10QFN |
3716 | 1.47 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 10V ~ 18V | Not Required | 5A | 40mOhm | Non-Inverting | Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MP62551DJ-LF-ZIC PWR SWTCH N-CHAN 1:1 TSOT23-6 |
2970 | 1.54 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 2.5V ~ 5.5V | Not Required | 1.5A | 100mOhm | - | Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, UVLO | -40°C ~ 85°C (TA) | Surface Mount |
|
|
MP5016HGQH-ZIC PWR LMT SWITCH N-CH 1:1 10QFN |
2215 | 1.68 |
Add To CartInquiry Now |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 22V | 2.7V ~ 22V | 5A | 43mOhm | - | Slew Rate Controlled | Over Current, Over Voltage | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
MP5036GJ-P12V, 0.4A TO 5A, CURRENT LIMIT S |
3961 | 1.57 |
Add To CartInquiry Now |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | General Purpose | 1 | 1:1 | Low Side | P-Channel | - | 2.9V ~ 14V | Not Required | 5A | 43mOhm | - | Load Discharge, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Over Voltage, UVLO | -40°C ~ 125°C (TJ) | Surface Mount |
